MTD 462 thru 465 - Manual (Page 15)

15
REF.
NO.
PART
NO. DESCRIPTION
1 731-1899 Chipper Chute
2 728-0175 Pop Rivet
3 735-0249 Chute Flap
4 781-0633 Flat Strip
5 710-0751 Hex Cap Screw 1/4-20 x .620
6 681-0068 Chipper Chute Am
7 736-0173 Flat Washer.28 ID x .74 OD
8 710-0106 Hex Cap Screw 1/4-20 x 1.25
9 749-1004 Chute Support
10 712-3027 Hex Flange Nut 1/4-20
11 710-0106 Hex Cap Screw 1/4-20 x 1.25
12 712-3010 Hex Nut 5/16-18
13 736-0242 Bell Washer.340 ID x .872 OD
14 681-0095 Complete Chipper Chute
15 712-3010 Hex Nut 5/16-18
16 736-0242 Bell Washer .340 ID x .872 OD
17 681-0094 Chute Asm
18 720-0170 Knob 5/16-18
19 714-0149B Cotter Pin
20 781-0457 Shredder Screen
21 711-0835 Clevis Pin
22 712-3027 Hex Lock Nut 1/4-20
23 712-3004A Flange Hex Lock Nut 5/16-18
24 750-0793 Spacer
25 681-0117 Rear Housing Asm
26 726-0211 U Nut 5/16-18
27 781-0510B Shredder Frame
28 710-0805 Hex Cap Screw 5/16-18 x 1.5
29 736-0170 Bell Washer 5/16 x 1.0
30 710-3008 Hex Cap Screw 5/16-18 x .75
31 710-0157 Hex Cap Screw 5/16-24 x .75
32 736-0119 Lock Washer 5/16
33 736-0329 Lock Washer 1/4
34 710-0599 Hex Washer Screw 1/4-20 x .5
35 712-3004A Hex Lock Nut 5/16-18
36 710-1502 Hex Washer Screw
37 751-0646 Muffler Bracket Guard
38 751-0447 Deflector
39 710-1054 Flat Screw 5/16-24 x 1.0
40 781-0490 Chipper Blade
41 712-0411 Hex Lock Nut 5/16-24
42 681-0030 Impeller Asm
43 742-0571 Shredder Blade
44 736-0119 Lock Washer 5/16
45 719-0329 Flail Blade
46 715-0166 Spiral Pin
47 781-0735 Spring Pin
48 710-1254 Hex Cap Screw 3/8-24 x 2.25
49 736-0217 Lock Washer 3/8
50 736-0247 Flat Washer 3/8 x 1.25
51 726-0214 Push Cap
52 734-1600 Wheel Assy Comp 10.0 x 2.5
734-1597 Wheel Assy Comp 10.0 x 4 x 4
734-1455A Rim Assy Comp.
734-1598 Tire Only
734-0255 Air Valve
737-0211A Grease Fitting
53 681-0004A Front Housing Asm
54 710-0825 Hex Cap Screw 1/4-20 x 3.75
55 734-1455A Rim
56 738-0814 Shredder Axle 21.2” (462 or 463)
738-0813 Shredder Axle 22.5” (465)
57 750-0786 Spacer
58 741-0487A Flange Bearing
59 781-0515 Support Bracket
60 781-0574 Shredder Plate
61 681-0104 Bracket Asm
62 750-0785 Spacer
63 732-0306 Compression Spring
64 736-0117 Flat Washer 3/8 x .620 x .033
65 714-0104 Cotter Pin
66 736-0264 Flat Washer
67 711-1128 Release Rod
68 736-0264 Flat Washer .330 ID x .630 OD
69 712-0429 Hex Lock Nut 5/16-18
70 710-0376 Hex Cap Screw 5/16-18 x 1.0
71 736-0362 Flat Washer .320 ID x 1.25 OD
72 731-1710 Collar-Hopper
73 681-0123 Hopper Bracket Asm
74 731-1707 Hopper
75 710-3008 Hex Cap Screw 5/16-18 x .75
76 711-0833B Clevis Pin
77 737-0195 Oil Drain Elbow (Not Shown)
723-0400 Safety Glasses (Not Shown)
764-0199A Bag (Not Shown)
REF.
NO.
PART
NO. DESCRIPTION
Model Series 462 thru 465
