Baracoda BCM 2604 - Manual (Page 20)

Interleaved 2 of 5
3.6.1 Check Digit
No Check Digit indicates that the imager reads and transmits bar code data with or without a check
digit.
When Check Digit is set to Validate, but Don’t Transmit, the unit only reads Interleaved 2 of 5 bar
codes printed with a check digit, but will not transmit the check digit with the scanned data.
When Check Digit is set to Validate and Transmit, the imager only reads Interleaved 2 of 5 bar codes
printed with a check digit, and will transmit this digit at the end of the scanned data. Default = No
Check Digit
3.6.2 Interleaved 2 of 5 Message Length
Scan the bar codes below to change the message length. Refer to Message Length Description
(chapt 3.2) for additional information. Minimum and Maximum lengths = 2-80. Minimum Default = 4,
Maximum Default = 80
3.7 Code 93
< Default All Code 93 Settings >
Code 93
19
* On
Off
Minimum Message Length
Maximum Message Length
