LIMIT THERMOSTAT

Location:

The limit thermostat is located inside the top

access panel on the front side of the tank.

Test Procedures:
1. Disconnect the brewer from the power source.
2. Disconnect the blue and black wires from the limit

thermostat.

3. With an ohmmeter, check for continuity across the

limit thermostat terminals.

If continuity is present as described, the limit thermo-
stat is operating properly.
If continuity is not present as described, replace the
limit thermostat.
