CONTENTS
Your 3DR Y6 Kit contains:
Metal nuts (23)
Nylon nuts (8)
5 mm nylon bolts (40)
6 mm steel bolts (12)
25 mm steel bolts (20)
30 mm steel bolts (2)
35 mm steel bolts (3)
11” zip ties (6)
18 mm threaded spacers (12)
19 mm hollow spacers (13)
Thumb nuts (5)
Accessory
plate
APM plate
Top plate
Co-axial motor
mounting plates (6)
C-type landing gear
plates (6)
You will also need:
Black arm (1)
Blue arm (2)
Battery straps (2)
850 Kv motors with
bullet connectors (6)
Option: 880 Kv motors
10 x 4.7 SF (normal) propellers (1)
10 x 4.7 SFP (pusher) propellers (2)
11 x 4.7 SFP (pusher) propellers (1)
11 x 4.7 SF (normal) propellers (2)
Electronic speed
controllers (6)
Power module with XT60
connectors
Deans connectors - male (6)
6-position power
module cable
» Phillips screwdriver (small)
» 5.5 mm (7/32) wrench
» Double-sided foam mounting tape
These instructions require some minor
soldering. If you’re unfamiliar with
soldering, our friends at Sparkfun have
some great tutorials that can get you
started, including this comic:
learn.sparkfun.com/curriculum/42 .
For an example of exactly what you’ll
be doing for this assembly (soldering
Deans connectors to ESCs), check out
this video: youtu.be/3LJIQeKuLLU .
Heat shrink tubing
Bottom plate
» 2 mm (5/64) hex wrench
» Soldering equipment
» Blue threadlocking compound
30 mm threaded spacers (8)
Double-adhesive foam mounting squares (4)
Two-wire RC receiver cable
Six-wire RC receiver cable
Motor collets (4)
Power distribution board
