Yamato Scientific BM200 Water Baths - Manual (Page 3)

1
1. Specifications
Model BM100 BM200
Temp. range during operation Room temp. +5 ℃ ~ 95℃ *1
Temp. setting range 0 ℃ ~ 100℃
Accuracy of temp. adjustment *2 ± ± ± ±2 ℃ at 60℃
Control system ON/OFF control
Set-up system Analog set-up
Display system Thermometer
Operation function Operation at fixed point
Extra function No extra function
Thermoregulator Liquid-operated thermoregulator
Material SUS316 pipe heater
Heater
Capacity 500W 1kW
Power switch Paddle switch
Power lamp Lit when power is on
- Drain (with plug)
Others
- Service outlet for RE
Safety device Protection from overcurrent (fuse), Thermofuse
Capacity 4 ml 7 ml
Tank
Dimension *3 Φ200×Depth 120 (mm) Φ240×Depth 150 (mm)
External dimensions (W ×D×H) *3 240 Ч300Ч150 (mm) 310 Ч360Ч230 (mm)
Weight 7.7lb (3.5kg) 13.3lb (6kg)
Required power source AC100V ± ± ± ±10% 50/60Hz 5 A AC100V ± ± ± ±10% 50/60Hz 10A
Liquid used Water
Standard accessories
● Bar Thermometer
( -10℃∼110℃ with immersion line) 1
● Fuse ( BM100 7A, BM200 15A ) 1
● Instruction manual 1
● Warranty 1
*1 In case of unloaded operation of bath only. The maximum temperature varies on circumstances
and operational conditions.
*2 It shows the performance under rated power supply at the room temperature of 23 ℃± ± ± ±5℃ and with
humidity of 65% ± ± ± ±20%.
*3 It does not include projection parts.
