Rev 24.0/5-14 6 VLGG10-DC: #35164
ASSEMBLY
1) Open the shipping container and remove all materials for restraining or protecting the vacuum
lifter. Save the container for use whenever the lifter is transported.
2) Suspend the lifter from a crane as follows: Select hoisting equipment (crane and hoist, when
applicable) rated to carry the maximum load weight plus the lifter weight (see
SPECIFICATIONS: Maximum Load Capacity and Lifter Weight).
Note: Any application of the lifter must conform to all statutory or regulatory standards that
relate to the hoisting equipment when used in its geographical location (eg, relevant OSHA
standards in the USA).
Make sure the lift slings are securely attached to the lifter. Then attach the free eye of each
lift sling onto the hoisting equipment hook.
WARNING: Hoisting equipment hook must be fitted with restraining latch to
prevent lift slings from slipping off under any circumstances.
Note: It may be desirable to use a large clevis to connect the lift slings to the hoisting
equipment hook. This makes suspending the lifter easier, since only the clevis must be
attached to or removed from the hoisting equipment hook.
WARNING: Clevis and clevis pin must be rated to carry maximum load weight
plus lifter weight.
Use the hoisting equipment to raise the lifter out of the shipping container. Be careful to
avoid damaging any vacuum pads. Remove the pad covers and save them for use whenever
the lifter is stored. Now the lifter is operational.
3) Connect the electrical connectors uniting the battery to the battery charger and the vacuum
generating system.
4) Perform Operational and Load Tests for the lifter as directed in MAINTENANCE: T
ESTING
S
CHEDULE
.
