Rev 24.0/5-14 3 VLGG10-DC: #35164
SPECIFICATIONS
Description: Designed for use with a crane or other hoisting equipment, the VLGG10-DC lifters
employ vacuum to hold a load for lifting in the upright orientation.
Model Number: VLGG109DC VLGG1011LDC
Vacuum Pads: (standard rubber, spring-mounted for ¼" [7 mm] travel, with #60 filter screen)
Ten 9" [23 cm] nominal
diameter (Model VPFS9)
Ten 11" [28 cm] nominal
diameter, lipped (Model G3370)
Maximum Pad Spread: 51¼" x 117½" 53¾" x 120"
(to outer edges) [1302 x 2985 mm] [1365 x 3048 mm]
Lifter Weight: 202 lbs [92 kg] 213 lbs [97 kg]
Load Capacity: (rated at 16" Hg [-54 kPa] on clean, smooth, nonporous flat surfaces 1 )
Per-Pad: 120 lbs [54.5 kg] 180 lbs [81.5 kg]
Maximum: 1200 lbs [545 kg] 1800 lbs [815 kg]
Power Source: 12 volts DC, 26 amps
Battery Capacity: 26 amp-hours
Vacuum Pumps: 2 diaphragm type, 1 SCFM [28 liters/minute] nominal airflow or
1 diaphragm type, 3 SCFM [85 liters/minute] nominal airflow
Vacuum Reserve Tank: Vacuum reservoir helps prevent immediate vacuum loss in case of power failure
and extends battery life by reducing pump cycles required to maintain vacuum.
Vacuum Gauge: Dial gauge indicates current vacuum level in positive inches of Hg and negative
kPa.
Vacuum Lift Light: Green light is energized whenever vacuum level is sufficient for lifting maximum
load weight (higher than 16" Hg [-54 kPa]).
Options: See separate instructions about optional features.
Operating Elevation: Maximum = 7000 feet [2133 meters]
Operating Temperatures: 32° to 104° F [0° to 40° C]
Service Life:
This lifter is designed to have a service life of at least 20,000 lifting cycles, when
used and maintained as intended. Vacuum pads, filter elements and other wear-
out items are excluded; see MAINTENANCE and REPLACEMENT PARTS LIST for
more information. For the D ISPOSAL OF THE L IFTER after its service life, see
INTENDED USE.
ASME Standard BTH-1: Design Category "B", Service Class "0" (see www.powrgrip.com for more
information)
!!-CE-!! Note: This symbol appears in the INSTRUCTIONS manual only when requirements of a CE Standard are
different from requirements of other standards that also apply to this vacuum lifter. CE requirements are mandatory
in geographical areas where CE Standards apply, but may be optional in other locations.
1
Load Capacity is based on a friction coefficient of 1; see MAINTENANCE: V ACUUM P AD M AINTENANCE : Friction Coefficient for
additional information.
