WARNING: Closing any pad shutoff reduces lifting capacity.
To activate a pad, open the pad shutoff (place valve lever parallel with
vacuum line); to deactivate a pad, close the pad shutoff (place valve lever
perpendicular to vacuum line). To calculate the lifting capacity when some
pads are deactivated, consult the Per-Pad Load Capacity rating (see
SPECIFICATIONS) and multiply by the number of pads currently
activated. Always activate pads in a symmetrical configuration, to keep
the lifter balanced while lifting, and use as many pads as possible for
each load being lifted, to maximize lifting capacity and to minimize load
overhang.
T
O
A
PPLY THE
P
ADS TO A
L
OAD
Powering up the Vacuum Package
Place the power switch in the ON ( ) position (blue indicator light remains illuminated while
power is engaged). The power switch must remain in the ON position while operating the lifter. 4
WARNING: Never turn power off while operating lifter.
Placing the power switch in the OFF ( ) position during lifter operation could result in the
release of the load and possible injury to the operator.
Positioning the Lifter on the Load
Make certain that the contact surfaces of the load and all vacuum pads are free of any
contaminates that could prevent the pads from sealing against the load (see MAINTENANCE:
V
ACUUM
P
AD
M
AINTENANCE
).
The lifter is designed to automatically carry the load in an upright orientation. Center the pad
frame from left to right on the load. Determine which will be the top edge of the load while
lifting, and position the long row of vacuum pads near that edge.
5 This position will maximize
stability while lifting the load. Make sure that all activated pads will fit entirely on the load’s
contact surface (see SPECIFICATIONS: Pad Spread) and that they will be loaded evenly while
lifting. Then apply the lifter to the load so that all activated pads are touching the contact
surface (see SPECIFICATIONS: Per-Pad Load Capacity).
4
If a vacuum pump fails to function while the power switch is in the ON position, examine the circuit breaker (adjacent to power
switch) to determine whether it has interrupted the electrical circuit to the component. Although the operator can reset the
circuit breaker, the power interruption may indicate an electrical problem that requires attention. Correct any deficiency before
resuming normal operation of the lifter (see wiring diagram provided).
5
This is the only row of pads on models MT4HV11FDC and MT6HV11FDC.
CLOSED
PAD SHUTOFF VALVE
