8
Blade Removal and cleaning
1. Set the counterplate back to the "0" position.
2. After removing the removable carriage, remove
the blade cover by turning the black knob
located behind the blade counterclockwise.
3. Clean blade cover in the sink or with a spray
cleaner.
4. When the blade cover is removed, you can clean
the blade.
5. Clean the front of the blade with a moist sponge
or cloth. Most, but not all, of the back of the
blade can be cleaned in a similar manner by
carefully rotating the front the blade by hand
(touch only the flat side of the blade, not the
edges). Clean the blade cover in the sink or with
a spray cleaner.
6. To completely remove the blade for cleaning, use
an Allen wrench to carefully remove the screws
that connect the blade to the base.
USE EXTREME cAUTION.
7. Clean the blade with a moist sponge or cloth,
cAUTION: Pay close attention the edge of the
blade.
8. To reassemble, screw the blade back in and
replace the blade cover over the blade by lining
up the cover and turning the knob clockwise to
secure it into place.
9. Now you can replace the removable carriage
(see “carriage removal” instructions, Page 7).
DO NOT WASH ANY PART OF THIS SlIcER
IN A DISHWASHER.
This piece will
come off
Using an Allen wrench
unscrew the 3 screws
holding the blade.
Remove blade.
Do not touch the
sharp outer edge.
Knob in back of unit
turns counterclockwise
