9

8

Spar

a

ar

p

c

®

RED DO T

The SPARC red dot

includes a removable 2x magnifier which may be used

for longer distance shooting. To attach the
magnifier, thread it into the eyepiece end
of the scope. Use the focus dial to adjust for
sharpest image.

Magnifier

m

ounTS

for

The

SPArC

To get the best results from the Vortex SPARC red dot, proper mounting
is essential. Although not difficult, the correct steps must be followed. If
you are unsure of your abilities, it would be
best to use the services of a qualified gunsmith.

The SPARC can be mounted on a variety
of platforms using various combinations of
the included risers and shim.

Vortex recommends using a thread locker compound to ensure attachment
screws do not loosen under use.
• When changing mount risers, use the included hex wrench to loosen or
tighten the four screws attaching the mount riser to SPARC body.

• When using the riser shim, install between mount riser and body of
SPARC. It will also be necessary to use the longer attachment screws when
the shim is being used.

Extra-High Mount Height

Use the tall riser and riser shim to provide
lower 1/3 co-witness on flat top AR-15 rifles.

(40 mm)

High Mount Height

Use the tall riser alone to provide absolute
co-witness on flat top AR-15 rifles.

(37 mm)

Use the short riser alone for most
applications other than flat top AR-15 rifles.

Low Mount Height

(18 mm)

Use the short riser with the shim to add
additional height if needed.

Low Mount Height

(21 mm)

Riser Shim

Tall Riser

Short Riser

2x Magnifier

2x Magnifier
included with
SPARC

(Shown on Tall Riser)

Rotate dial to sharpen
the image focus.

Focus Dial
