1. Unscrew the outer cap with a coin.
2. Remove the battery.
3. Replace with a new CR 2032 battery.
4. Install battery with plus (+) side up.
Battery Replacement
Reticle Illumination Adjustment
Some Crossfire II riflescope models offer an illuminated reticle that is
controlled by an adjustment knob on the eyepiece. Adjust the illumination
intensity by rotating the knob either clockwise or counter-clockwise.
7 6
RIFLESCOPE
II
Warning
Looking directly at the sun through a
riflescope, or any optical instrument, can
cause severe and permanent damage to
your eyesight.
Variable Power Adjustments
To change magnifications, turn
the magnification ring to the
desired level.
Magnification
Scale Battery cover on top
of adjustment knob.
