SINK SPECIFICATIONS

SINGLE BOWL Farmhouse

Model

VG3020C

MODEL # BOWL SIZE SINK DEPTH EXTERIOR GAUGE

VG3020C

9 7/8"

30" x 22 1/4"

16

28" x 18"

DIM.

NOMINAL DIMENSIONS

TOP VIEW

FRONT VIEW

30" [764mm]

22 1/4" [566mm]

28" [712mm]

FEATURED MODEL

VG3020C

9 7/8" BOWL DEPTH

FEATURES

16 gauge, stainless steel

304 Nickel - Bearing Content
Zero radius corners

Elegant and functional drain grooves
Long-lasting, easy-to-clean, satin finish

Sound-deadening insulation

Rear drain placement
Round apron front

PACKING LIST

-

SINK

9 "

[230mm]

9 7/8"

[250mm]

10 1/2" [267mm]

18" [457mm]

21 1/2" [547mm]

1
