SINK SPECIFICATIONS
SINGLE BOWL Farmhouse
Model VGR3020C
MODEL # BOWL SIZE SINK DEPTH EXTERIOR GAUGE
VGR3020C 9 7/8" 30" x 22 1/4" 16 28" x 18"
DIM.
NOMINAL DIMENSIONS
TOP VIEW
FRONT VIEW
FEATURED MODEL VGR3020C
9 7/8" BOWL DEPTH
FEATURES
16 gauge, stainless steel
304 Nickel - Bearing Content
15 radius corners
Elegant and functional drain grooves
Long-lasting, easy-to-clean, satin finish
Sound-deadening insulation
Rear drain placement
Round apron front
PACKING LIST
- SINK
1
18" [457mm]
22 1/4" [566mm]
30" [764mm]
9 7/8" [250mm]
28" [712mm]
PACKING LIST
- SINK
21 5/8" [547mm]
9" [230mm]
10 1/2" [267mm]
