SBB00104-1-1107 Page 11
1. Remove the surround from the shipping box and place the
SBB surround into position in the constructed enclosure. See
Figure 1.
2. Secure the SBB surround to the enclosure using up to
eight screws (not provided). See Figure 2.
Note: If you have a masonry structure you may need to
substitute for the appropriate masonry fasteners.
Figure 1
Figure 2
3. Slide grill head with flex gas line attached into surround. Make
sure flex gas line is protruding out surround side. See Figures
3 and 4.
Figure 4
Figure 3
SURROUND AND GRILL ASSEMBLY
SURROUND ASSEMBLY
