EL Series UV Lamps Page 4
95-0200-02 230/50/0.16
95-0200-03 100/50-60/0.16
UVL-18 95-0198-01 115/60/0.16 365nm/White (one tube each)
95-0198-02 230/50/0.16
95-0198-03 100/50-60/0.16
UVM-18 95-0199-01 115/60/0.16 302nm/White (one tube each)
95-0199-02 230/50/0.16
95-0199-03 100/50-60/0.16
UVS-28 95-0249-01 115/60/0.32 254nm (two tubes)
95-0249-02 230/50/0.32
95-0249-03 100/50-60/0.32
UVL-28 95-0248-01 115/60/0.32 365nm (two tubes)
95-0248-02 230/50/0.32
95-0248-03 100/50-60/0.32
UVM-28 95-0250-01 115/60/0.32 302nm (two tubes)
95-0250-02 230/50/0.32
95-0250-03 100/50-60/0.32
UVLS-28 95-0201-01 115/60/0.16 365/254nm (one tube each)
95-0201-02 230/50/0.16
95-0201-03 100/50-60/0.16
UVLM-28 95-0251-01 115/60/0.16 365/302nm (one tube each)
95-0251-02 230/50/0.16
95-0251-03 100/50-60/0.16
UVLMS-38 95-0252-01 115/60/0.16 365/302/254nm (one tube each)
95-0252-02 230/50/0.16
95-0252-03 100/50-60/0.16
Operation
Safety Precautions
Shortwave and midrange UV radiation will cause damage to unprotected eyes and skin.
Before operating any unit, be sure all personnel in the area are properly protected. UV
Blocking Eyewear should be worn as well.
Using the Lamp
Plug power cord into a properly grounded electrical outlet. The proper voltage of the
lamp is found on the product information label.
The power switch is conveniently located on top of the unit to turn the lamp on or off.
For models with multiple wavelengths the switch allows selection of wavelength or to shut
the unit off.
Each lamp comes with two UV tube or one UV and one white light tube. The UVLMS-38
is equipped with three tubes. Models with two tubes of the same wavelength operate with
both tubes on at the same time. Other models operate with only a single tube a time.
