Carrier Installation
Figure 12. Front Weight Carrier Installation
A. Holes
D. Rod
B. Capscrews, E. Clips,
Safety
1/2-13 x 1-1/4
F. Carrier, Weight
C. Locknuts, 1/2-13
FRONT WEIGHT CARRIER INSTALLATION
1. Install carrier (F, Fgure 12) as shown securing with
capscrews (B), and locknuts (C).
2. Secure required weights using rod (D) and safety
clip (E).
D
F
B
B
E
E
A
A
C
C
