3. Test the operation. If the trigger has insufficient force to make the
lock function, turn the screw counterclockwise very gradually
until the lock functions. Backing the screw off too far will cause a
condition where the lock hammer will not remain in full cock
(second position) adjust the trip lever as follows:
LOCK ADJUSTMENT
If the lock of your gun functions properly as described in the Loading
and Shooting Instructions, do not attempt to adjust it. If in the rare event
adjustment is necessary, carefully make the following adjustments.
An adjustment screw is located on the lock tumbler. Turning this screw
clockwise will reduce the engagement of the sear point on the tumbler.
(See diagrams.)
CAUTION: Be extremely careful that the sear engages fully on the face of the
tumbler. If it does not, a dangerous “hair-trigger condition” will exist with the dan-
ger of accidental firing. To reduce this danger, turn the adjustment screw counter-
clockwise to obtain more sear engagement.
Note: Lock Removal Hint
On most models the ramrod retaining spring is attached to the stock by the
the lock plate screw closest to the barrel tenon pin or wedge. If that lock
plate screw is unscrewed entirely, the spring may become dislodged in the
stock. As a preventative measure, partially loosen that lock plate screw.
Place a piece of tape over screw head to hold the screw (and ramrod retain-
ing spring) in place. Unscrew the remaining lock plate screw. Remove the
lock from the stock.
14
PROPER HALF-COCK SEAR POSITION
PROPER FULL-COCK SEAR POSITION IMPROPER FULL-COCK SEAR POSITION
IMPROPER HALF-COCK SEAR POSITION
