Thrush ASL Air Separators - Manual (Page 7)

Thrush Co.
Manual #9636-1220
3.1.1 Removable Strainer Option
The removable strainer option is a rolled 304 stainless perforated cylinder that allows the
user to easily remove the strainer for cleaning and /or inspection (Figure 3-2).
System water over 100°F can be very hazardous. Keep flow away from the body
when flushing the unit or removing the strainer. Failure to do so could result in
serious bodily injury or property damage.
Figure 3-2 Strainer
3.2 Optional Connections
The standard inlet and outlet flanged connections can be replaced with an alternate
grooved end pipe connection (Figure 3-3). This comes with or without strainer option.
FLANGED NOZZLE FOR
AS MODEL ONLY
Figure 3-3 Grooved End Connection
