Fiber-Classic
Door Panel
Dimensions
Comp 4 2014 (U1 REVISED) 4.37
8/0 Fiber-Classic Oak Doors
A
C
95-3/64”
F
D
E
B
G
Size A C F
3/0 35-13/16” 24-1/8” 5-27/32” 82-1/8” 7-51/64” 5-1/8” 6-11/32”
3/0 Impact 35-13/16” 23-7/8” 5-31/32” 81-7/8” 7-55/64” 5-1/4” 6-11/32”
A
C
95-3/64”
F
D
E
B
G
Size A C F
2/8 31-13/16” 24-1/8” 3-27/32” 82-1/8” 7-51/64” 5-1/8” 4-11/32”
2/8 Impact 31-13/16” 23-7/8” 3-31/32” 81-7/8” 7-55/64” 5-1/4” 4-11/32”
2 /10 33-13/16” 24-1/8” 4-27/32” 82-1/8” 7-51/64” 5-1/8” 5-11/32”
2 /10 Impact 33-13/16” 23-7/8” 4-31/32” 81-7/8” 7-55/64” 5-1/4” 5-11/32”
8’ Full Lite w/ Stile Lines
(Impact - 808H, 818H, 828H)
(Slab - FCO8060U1)
(Impact - FCO8060HU1)
8’ Full Lite w/ Stile Lines
(Impact - 808H, 818H, 828H)
(Slab - FCO8060U1)
(Impact - FCO8060HU1)
B D E G
B D E G
23-1/8”
23-1/8”
Daylight Opening: 20-13/16" x 78-13/16"
(1640 sq.in.)
Daylight Opening: 20-13/16" x 78-13/16"
(1640 sq.in.)
Note:
For Optional Grille Locations,
See Arch 1.
Note:
For Optional Grille Locations,
See Arch 1.
