Page 15
Fiber-Classic
Door Panel
Dimensions
Comp 4
2014 (U1 REVISED)
4.15
8/0 Fiber-Classic Mahogany
Embossed Doors
Daylight Opening: 18-15/16" x 78-15/16"
(2080 for 1" glass) (1495 sq.in.)
Daylight Opening: 19-1/8" x 79-1/8"
(2080 for 1/2" glass) (1513 sq.in.)
Daylight Opening: 18-15/16" x 78-15/16"
(2080 for 1" glass) (1495 sq.in.)
Daylight Opening: 19-1/8" x 79-1/8"
(2080 for 1/2" glass) (1513 sq.in.)
Daylight Opening: 20-15/16" x 78-15/16"
(2280 for 1" glass) (1653 sq.in.)
Daylight Opening: 21-1/8" x 79-1/8"
(2280 for 1/2" glass) (1672 sq.in.)
Size
A
B
C
D
E
F
2/8
31-13/16”
22-1/8”
4-27/32”
82-1/8”
7-51/64”
5-1/8”
2/8 Impact
31-13/16”
21-7/8”
4-31/32”
81-7/8”
7-55/64”
5-1/4”
2 /10
33-13/16”
24-1/8”
4-27/32”
82-1/8”
7-51/64”
5-1/8”
2 /10 Impact 33-13/16”
23-7/8”
4-31/32”
81-7/8”
7-55/64”
5-1/4”
3/0
35-13/16”
24-1/8”
5-27/32”
82-1/8”
7-51/64”
5-1/8”
3/0 impact
35-13/16”
23-7/8”
5-31/32”
81-7/8”
7-55/64”
5-1/4”
A
C
95-3/64”
F
D
E
B
Size
A
B
C
D
E
F
2/6
29-13/16”
22-1/8”
3-27/32”
82-1/8”
7-51/64”
5-1/8”
2/6 Impact
29-13/16”
21-7/8”
3-31/32”
81-7/8”
7-55/64”
5-1/4”
2/8
31-13/16”
22-1/8”
4-27/32”
82-1/8”
7-51/64”
5-1/8”
2/8 Impact
31-13/16”
21-7/8”
4-31/32”
81-7/8”
7-55/64”
5-1/4”
A
C
95-3/64”
F
D
E
B
Note:
For Optional Grille Locations,
See Arch 1.
8’ Full Lite Flush
(8084, 8084N, 2280, 2080)
(Impact - 808H, 808NH, 818H,
818NH, 828H, 828NH)
(Slab - FCM8010U1)
(Impact - FCM8010HU1)
8’ Full Lite Flush
(8084N, 2080)
(Impact - 808NH, 818NH, 828NH)
(Slab - FCM8010U1)
(Impact - FCM801HU1)
Note:
For Optional Grille Locations,
See Arch 1.
