Sills
Comp 12 2014 (BOOK SIZE) 12.11
Composite Outswing Sill
LENGTHS
"A"
SILL
LENGTH
"G"
OVERALL
LENGTH
24 = 2/4 DOOR 28.156 28.626
26 = 2/6 DOOR 30.156 30.626
28 = 2/8 DOOR 32.156 32.626
21 = 2/10 DOOR 34.156 34.626
30 = 3/0 DOOR 36.156 36.626
36 = 3/6 DOOR 42.156 42.626
407 = 4/0 DOUBLE 7/8" ASTRAGAL 49.062 49.532
487 = 4/8 DOUBLE 7/8" ASTRAGAL 57.062 57.532
507 = 5/0 DOUBLE 7/8" ASTRAGAL 61.062 61.532
547 = 5/4 DOUBLE 7/8" ASTRAGAL 65.062 65.532
587 = 5/8 DOUBLE 7/8" ASTRAGAL 69.062 69.532
607 = 6/0 DOUBLE 7/8" ASTRAGAL 73.062 73.532
707 = 7/0 DOUBLE 7/8" ASTRAGAL 85.062 85.532
405 = 4/0 DOUBLE 5/8" ASTRAGAL 48.906 49.376
485 = 4/8 DOUBLE 5/8" ASTRAGAL 56.906 57.376
505 = 5/0 DOUBLE 5/8" ASTRAGAL 60.906 61.376
545 = 5/4 DOUBLE 5/8" ASTRAGAL 64.906 65.376
585 = 5/8 DOUBLE 5/8" ASTRAGAL 68.906 69.376
605 = 6/0 DOUBLE 5/8" ASTRAGAL 72.906 73.376
705 = 7/0 DOUBLE 5/8" ASTRAGAL 84.906 85.376
407* = 4/0 DOUBLE 7/8" ASTRAGAL 49.062 49.532
487* = 4/8 DOUBLE 7/8" ASTRAGAL 57.062 57.532
507* = 5/0 DOUBLE 7/8" ASTRAGAL 61.062 61.532
547* = 5/4 DOUBLE 7/8" ASTRAGAL 65.062 65.532
587* = 5/8 DOUBLE 7/8" ASTRAGAL 69.062 69.532
607* = 6/0 DOUBLE 7/8" ASTRAGAL 73.062 73.532
707* = 7/0 DOUBLE 7/8" ASTRAGAL 85.062 85.532
48 = 4/8 2-PANEL PATIO 57.312 57.782
50 = 5/0 2-PANEL PATIO 61.312 61.782
54 = 5/4 2-PANEL PATIO 65.312 65.782
58 = 5/8 2-PANEL PATIO 69.312 69.782
60 = 6/0 2-PANEL PATIO 73.312 73.782
24D*0 = 2/4 WITH 1-10" SIDELITE 39.156 39.626
24D*2 = 2/4 WITH 1-12" SIDELITE 41.156 41.626
24D*4 = 2/4 WITH 1-14" SIDELITE 43.156 43.626
26D*0 = 2/6 WITH 1-10" SIDELITE 41.156 41.626
26D*2 = 2/6 WITH 1-12" SIDELITE 43.156 43.626
26D*4 = 2/6 WITH 1-14" SIDELITE 45.156 45.626
28D*0 = 2/8 WITH 1-10" SIDELITE 43.156 43.626
28D*2 = 2/8 WITH 1-12" SIDELITE 45.156 45.626
28D*4 = 2/8 WITH 1-14" SIDELITE 47.156 47.626
21D*0 = 2/10 WITH 1-10" SIDELITE 45.156 45.626
21D*2 = 2/10 WITH 1-12" SIDELITE 47.156 47.626
21D*4 = 2/10 WITH 1-14" SIDELITE 49.156 49.626
30D*0 = 3/0 WITH 1-10" SIDELITE 47.156 47.626
30D*2 = 3/0 WITH 1-12" SIDELITE 49.156 49.626
30D*4 = 3/0 WITH 1-14" SIDELITE 51.156 51.626
36D*0 = 3/6 WITH 1-10" SIDELITE 53.156 53.626
36D*2 = 3/6 WITH 1-12" SIDELITE 55.156 55.626
36D*4 = 3/6 WITH 1-14" SIDELITE 57.156 57.626
ST
AN
DA
RD
M
UL
LI
O
N
7/
8"
A
ST
RA
G
AL
LENGTHS
"A"
SILL
LENGTH
"G"
OVERALL
LENGTH
48W = 4/8 2-PANEL PATIO 57.812 58.282
50W = 5/0 2-PANEL PATIO 61.812 62.282
54W = 5/4 2-PANEL PATIO 65.812 66.282
58W = 5/8 2-PANEL PATIO 69.812 70.282
60W = 6/0 2-PANEL PATIO 73.812 74.282
24W*0 = 2/4 WITH 1-10" SIDELITE 39.656 40.126
24W*2 = 2/4 WITH 1-12" SIDELITE 41.656 42.126
24W*4 = 2/4 WITH 1-14" SIDELITE 43.656 44.126
26W*0 = 2/6 WITH 1-10" SIDELITE 41.656 42.126
26W*2 = 2/6 WITH 1-12" SIDELITE 43.656 44.126
26W*4 = 2/6 WITH 1-14" SIDELITE 45.656 46.126
28W*0 = 2/8 WITH 1-10" SIDELITE 43.656 44.126
28W*2 = 2/8 WITH 1-12" SIDELITE 45.656 46.126
28W*4 = 2/8 WITH 1-14" SIDELITE 47.656 48.126
21W*0 = 2/10 WITH 1-10" SIDELITE 45.656 46.126
21W*2 = 2/10 WITH 1-12" SIDELITE 47.656 48.126
21W*4 = 2/10 WITH 1-14" SIDELITE 49.656 50.126
30W*0 = 3/0 WITH 1-10" SIDELITE 47.656 48.126
30W*2 = 3/0 WITH 1-12" SIDELITE 49.656 50.126
30W*4 = 3/0 WITH 1-14" SIDELITE 51.656 52.126
36W*0 = 3/6 WITH 1-10" SIDELITE 53.656 54.126
36W*2 = 3/6 WITH 1-12" SIDELITE 55.656 56.126
36W*4 = 3/6 WITH 1-14" SIDELITE 57.656 58.126
24D10 = 2/4 WITH 2-10" SIDELITES 50.156 50.626
24D12 = 2/4 WITH 2-12" SIDELITES 54.156 54.626
24D14 = 2/4 WITH 2-14" SIDELITES 58.156 58.626
26D10 = 2/6 WITH 2-10" SIDELITES 52.156 52.626
26D12 = 2/6 WITH 2-12" SIDELITES 56.156 56.626
26D14 = 2/6 WITH 2-14" SIDELITES 60.156 60.626
28D10 = 2/8 WITH 2-10" SIDELITES 54.156 54.626
28D12 = 2/8 WITH 2-12" SIDELITES 58.156 58.626
28D14 = 2/8 WITH 2-14" SIDELITES 62.156 62.626
21D10 = 2/10 WITH 2-10" SIDELITES 56.156 56.626
21D12 = 2/10 WITH 2-12" SIDELITES 60.156 60.626
21D14 = 2/10 WITH 2-14" SIDELITES 64.156 64.626
30D10 = 3/0 WITH 2-10" SIDELITES 58.156 58.626
30D12 = 3/0 WITH 2-12" SIDELITES 62.156 62.626
30D14 = 3/0 WITH 2-14" SIDELITES 66.156 66.626
36D10 = 3/6 WITH 2-10" SIDELITES 64.156 64.626
36D12 = 3/6 WITH 2-12" SIDELITES 68.156 68.626
36D14 = 3/6 WITH 2-14" SIDELITES 72.156 72.626
70 = 7/0 TRIPLE PATIO 86.468 86.938
76 = 7/6 TRIPLE PATIO 92.468 92.938
80 = 8/0 TRIPLE PATIO 98.468 98.938
86 = 8/6 TRIPLE PATIO 104.468 104.938
90 = 9/0 TRIPLE PATIO 110.468 110.938
24W10 = 2/4 WITH 2-10" SIDELITES 51.156 51.626
24W12 = 2/4 WITH 2-12" SIDELITES 55.156 55.626
24W14 = 2/4 WITH 2-14" SIDELITES 59.156 59.626
26W10 = 2/6 WITH 2-10" SIDELITES 53.156 53.626
26W12 = 2/6 WITH 2-12" SIDELITES 57.156 57.626
26W14 = 2/6 WITH 2-14" SIDELITES 61.156 61.626
28W10 = 2/8 WITH 2-10" SIDELITES 55.156 55.626
28W12 = 2/8 WITH 2-12" SIDELITES 59.156 59.626
28W14 = 2/8 WITH 2-14" SIDELITES 63.156 63.626
21W10 = 2/10 WITH 2-10" SIDELITES 57.156 57.626
21W12 = 2/10 WITH 2-12" SIDELITES 61.156 61.626
21W14 = 2/10 WITH 2-14" SIDELITES 65.156 65.626
30W10 = 3/0 WITH 2-10" SIDELITES 59.156 59.626
30W12 = 3/0 WITH 2-12" SIDELITES 63.156 63.626
30W14 = 3/0 WITH 2-14" SIDELITES 67.156 67.626
36W10 = 3/6 WITH 2-10" SIDELITES 65.156 65.626
36W12 = 3/6 WITH 2-12" SIDELITES 69.156 69.626
36W14 = 3/6 WITH 2-14" SIDELITES 73.156 73.626
70W = 7/0 TRIPLE PATIO 87.468 87.938
76W = 7/6 TRIPLE PATIO 93.468 93.938
80W = 8/0 TRIPLE PATIO 99.468 99.938
86W = 8/6 TRIPLE PATIO 105.468 105.938
90W = 9/0 TRIPLE PATIO 111.468 111.938
