Guidance and manufacturer’s declaration — electromagnetic immunity
The SoloSpot
TM
Image Intensifier is intended for use In the electromagnetic environment specified
below. The customer or the user of the SoloSpot
TM
Image Intensifier should assure that it is used in
such an environment.
Immunity test
lEC 60601
test level
Compliance
level
Electromagnetic environment —
guidance
Electrostatic
discharge (ESD)
lEC 61000-4.2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floors should be wood, concrete or
ceramic tile, If floors are covered with
synthetic material, the relative humidity
should be at least 30 %.
Electrical fast
transient/burst
lEC 61000-4-4
±2 kV for power
supply lines
±2 kV for power
supply lines
Surge
lEC 61000-4-5
±1 kV differential
mode
±2 kV common
mode
±1 kV differential
mode
±2 kV common
mode
Mains power quality should be that of a
typical commercial or hospital
environment.
Voltage dips, short
Interruptions and
voltage variations
on power supply
Input lines
IEC 61000-4-11
<5 % U
T
(>95 %
dip In U
T
) for 0,5
cycle
40 % U
T
(60 % dip in U
T
)
for 5 cycles
70 % U
T
(30 % dip In U
T
)
for 25 cycles
<5% U
T
(>95 % dip In
U
T
) for 5 s
<5 % U
T
(>95 %
dip In UT) for 0.5
cycle
40 % U
T
(60 % dip in U
T
)
for 5 cycles
70 % U
T
(30 % dip in U
T
)
for 25 cycles
<5% U
T
(>95 % dip in U
T
)
for 5 s
Mains power quality should be that of a
typical commercial or hospital
environment, If the user of the
SoloSpot
TM
Image Intensifier requires
continued operation during power mains
Interruptions, It is recommended that
the SoloSpot
TM
Image Intensifier be
powered from an uninterruptible power
supply or a battery.
Power frequency
(50/60 Hz)
magnetic field
IEC 6 1000-4-8
3 A/m
0,3 A/m
If Image distortion occurs, It may be
necessary to position the SoloSpot
TM
Image Intensifier further from sources of
power frequency magnetic fields or to
install magnetic shielding. The power
frequency magnetic field should be
measured In the intended installation
location to assure that It is sufficiently
low.
NOTE U
T
is the a.c. mains voltage prior to application of the test level.
