9
CO
2
Regulator and CO
2
Cylinder
Note: Your CO
2
cylinder is shipped empty to avoid any possible accidents during
transportation. When you purchase the first keg of beer, have your beer distributor fill
the CO
2
cylinder. You must read and understand the following procedures for CO
2
cylinders before installation :
1. Install the CO
2
gas line tube to the regulator by attaching one end of the red tube to
the hose connection on the CO
2
regulator.
2. Secure the tube by using one of the self-locking black plastic snap-on clamps.
3. Insert a special washer into the regulator-to-cylinder attachment nut.
4. Attach the CO
2
regulator to the CO
2
cylinder by screwing the regulator nut onto the
cylinder valve and tightening with an adjustable wrench.
5. Remove the bolt with the nut from the cylinder retainer. Using two screws, attach it
inside the unit on the left side of the back wall. Holes are pre-drilled and screws are
included.
6. Slide the cylinder through the retainer and secure it with the bolt and the nut.
Position the cylinder this way so that you will be able to read the numbers on the
gauges and easily access the shut-off valves.
