SETTING MENU “SET”
6. Instrument select
1. Time/Date
2. Contrast/Brightness
3. Units
4. Language
5. Helpline
M
A
I
N
S
E
T
Select the SET menu and
perform in order the
following operations
FORWARD SPEED CALIBRATION
NB : Speed calibration is done over a distance of 100 m
• Mark out a distance of 100 m
• Position the tractor at the 1st mark
• Speed calibration is complete
• Press
ESC to exit.
6. Instrument select
1. Time/Date
2. Contrast/Brightness
3. Units
4. Language
5. Helpline
M
A
I
N
S
E
T
Select
1
1. 1.000 m/Pulse
2. 1.000 m/Pulse
3. 2.000 m/Pulse
4. 0.016 m/Pulse
M
A
I
N
S
E
T
ESC
2
Calibration over 100m Calibration over 100m
m/pulse 1,00000
Press to start
Speed factor
M
A
I
N
S
E
T
ESC
• Select “calibrate over
100 m”
• Press enter at 1st mark
3
Calibration over 100m
0m 100m
Now drive 100 metres
M
A
I
N
S
E
T
ESC
• Go forward 100 m
• Press enter at 2
nd mark
• Enter again to confi rm
4
0m 100m
• Select
tractor N°1
• Press on
0m 100m
0m 100m
5
