Vision ii dpb : q, Uick, Start guide

background image

1

VISION II DPB : Q

UICK

-

START GUIDE

Réf: 400 355

- 00 - GB / DIS

03/2008

Menu selection

Numeric keypad

Power On/Off

Factory parameters

and diagnostic

Backspace

Data confirmation

Á

There is a choice of 3 menus :

Spreading menu

(

MAIN

)

Information menu

(

INFO

)

Setting menu

(

SET

)

Á

Fit a speed sensor ideally on the front transmission shaft (a semi-circular magnet) or on the

wheels :

front wheel

Á

4 magnets

rear wheel

Á

8 magnets

If the tractor has a radar or speed sensor, it is possible to connect directly using a special
plug to the tractor's original socket.

Á

When setting up the DPB, follow these steps in order :

1

1

Calibrate the forward speed.

2

2

Set the working width.

3

3

Choose a product (A, B, C…).

4

4

Do a rate calibration test (T factor).

5

5

Set the quantity / ha.

GENERAL PRESENTATION
