MODEL 37641401 - 04
PeCo
ASSEMBLY
STEP 7:
Attach Boot Retainer to Boot with 3/8" x 1"
carriage bolts and 3/8" flange nuts as shown.
TIGHTEN NUTS AND BOLTS!
Lift mower deflector and hang Boot
Plate as shown.
STEP 8:
STEP 9:
Place Clamp over each end of Lower
Hose. Attach one end of hose over
the Blower Cone. Tighten Clamp.
Slide free end of hose over Boot and
tighten clamps.
9
