Rev. 1.14

- 16 -

SRP-770II

[Table 1] Dip Switch 1

No

Functions

Details

Off 4.0

ips

1-1 Speed

Selection

On 5.0

ips

4

3

2

Density

Off Off Off

13

Off Off On

14

Off On Off

15

Off On On

16

On Off Off

17

On Off On

18

On On Off

19

1-2

1-3

1-4

Density Selection

On On On

20

Off Normal

Mode

1-5 Exhibition

Selection

On Demo

Mode

Off Label

Paper

1-6 Media

Selection

On Thermal

Continuous

Paper

Off Without

Auto

Cuter

1-7 Auto

Cutter

On With

Auto

Cuter

Off Back Feeding Enable

1-8 Back

Feed

Option

On Back Feeding Disable


[Table 2] Dip Switch 2

No

Functions

Details

2

1

Baud Rate

Off Off

9,600

bps

Off On

19,200

bps

On Off

230,400

bps

2-1

2-2

Baud Rate Selection

On On

115,200

bps

Off Detect

Gap

2-3 Media

Detection

On Detect

Black-mark

2-4 Reserved

Default

---

off

2-5 Reserved

Default

---

off

2-6 Reserved

Default

---

off

Off Enable

2-7

Paper End Sensor

Status

On Disable

2-8 Reserved

Default

---

off




5-2 Pause/Restart

Press FEED button to pause at the middle of labels printing.

1) Press FEED once.

2) Printer stops after on-going printing and Red LED becomes on.

3) Press FEED once again. It restarts printing in a queue.
