Hybex® Microsample Incubator — USER MANUAL
Version 1.2H, October 2014 6 (408) 733-7337, [email protected]
II. UNPACKING AND SET UP
A. Unpacking the Heating Unit
The Hybex Microsample Incubator heating base is shipped on its side within the interior
carton. Remove any packing material around the unit and lift the unit out; taking care not to
damage the hinged cover. Carefully inspect the heating unit for damage.
If there is evidence of damage, do not discard the shipping materials since they may be
needed to return the unit.
Note: Heat blocks and other accessories are packaged separately from the heating base.
B. Parts Provided
The following items are included with the Hybex heating base within the
re-closable plastic bag:
• Power cord
• User Manual
C. Installation
1. Place the unit on a level surface within a few feet of the power source. Ensure the
lid can be opened completely without interference and leave 3 inches of clearance
along the back and sides for air circulation.
2. Plug the provided power cord into the back of the unit and then to a properly
grounded outlet. Use only the power cord provided.
Do NOT operate the system without a block inserted into the base unit!
Ne pas faire fonctionner le système sans un bloc insérée dans l'unité de base!
See Section VII. ORDERING INFORMATION for a list of available accessories and Section III.
B. Handling Tube Blocks and the Waterbath Insert for how to insert and remove blocks.
Allow 3 inches of clearance on both sides
Allow 15 inches of vertical
clearance to open the lid.
Allow 3 inches of clearance at
the back for the power cord.
