Ensure all gas valves are open
Check orifice for obstructions
(such as insects or cocoons)
Check proper size orifice hole
Replace orifice if necessary
Is gas getting through to the burner?
YES NO
Is there flame failure/ flame-out after the
spark generator has completed its ignition
cycle.
NO YES
Still having trouble operating the heater?
NO YES
Ensure the sensing wire is securely
connected to the sensing probe,
Check spark igniter for cracks.
Replace ignition control if necessary
Ensure the flame sensor is within
1I4” to 1/2” from the ceramic tile
TROUBLESHOOTING COMPLETE
Repeat the above troubleshooting
procedures. If the problem persists,
contact your Schwank distributor.
Cont’d
