FIGURE 6 END PLATE HANGER/ELBOW INSTALLATION
9– Focus shield Reflector ***
10- Flue Vent terminal
11- Burner Support Chain
12- Hanger Support Chains
13- Reflector Stabilizer **
Page 8
FIGURE 4 TYPICAL HANGER & SUPPORT SPACING RECOMMENDATIONS
5- Sight Glass
6- Aluminized Tube with Flange
7– Tube Coupler
8- Painted Steel Tube(s)
* Distances shown are recommendations and may be varied to match field requirements.
** This should only be used if the reflector is mounted on an angle.
*** Refer to section 10: Focus Shield Reflector Installation (page 12).
1- End Plate Hangers
2- Wire Hangers
3- Burner Assembly
4- Combustion Air Intake
FIGURE 5 HANGER ARRANGEMENTS
1 Two Wire Hangers per Each
Middle Section
2 Use End Plate Hangers at
Burner & Flue Ends (& each
side of any elbow)
3 End Plate Hanger Flange
UNDER Reflector
4 End Plate Hanger Flange
OVER Reflector
5 Butt Sight Glass Ring to
End Plate Hanger
10
13
2
11
4
3
5
6
8
7
9
1
1
12
3" 4"
"ALL TUBES MUST BE SUSPENDED BY TWO (2) HANGERS PER 10' LENGTH,
MOUNTED APPROXIMATELY 6" TO 12" IN FROM EACH TUBE END.
1
2
2
3 3
4
4
5
6
7
Note Exception: First and last hanger (end plate hangers) must be mounted 4” away from end of tube
1. End-Plate-Hangers 5. 90 0 (shown) or 180 0 Elbow
2. Focus Shield Reflectors 6. Tube/Elbow Coupler
3. End-Plate-Hanger Flange OVER Reflector 7. Point at which Swaged tube fits into elbow
4.End Plate Hanger Flange UNDER Reflector and Swaged end of elbow fits into tube.
1
5
2
4
3
ADDITIONAL
TUBE(S)
FIRST
TUBE
4”
