46
STR-JZ I&O Manual
IM090831
RD: AUG 2009
RL: 09A- BA
MODEL
TURBULATOR
LENGTH
(IF REQUIRED)
STR-JZ 60-30 14' (4.3 m)
STR-JZ 60-20 14' (4.3 m)
STR-JZ 45-20 14' (4.3 m)
STR-JZ 45-10 5’ (1.5 m)
NOTE: Improper location of a turbulator can cause malfunction of the heater,
property damage, and will void the heater warranty.
Tube Heaters are supplied with all required turbulator(s) factory installed into
the tube(s). Tubes with turbulators are installed at the vent end of the system
configuration and are clearly labeled for easy identification.
27. TURBULATORS:
