26. BURNER & TUBE KIT ASSEMBLY CHART MODELS STR-JZ
MODEL STR-JZ is approved for indoor residential garage / workshop application. For outdoor,
wet and harsh environment applications refer to models SPW-JZ / IWP (powder coated burner
box) and/or STW-JZ / IW (stainless steel burner box).
BEFORE INSTALLING: ENSURE you have the CORRECT TUBE KIT(s) for the
BURNER INPUT
USA: S/S Flexible Gas Connector is supplied with the Burner Kit
CANADA: Type 1 Hose Gas Connector is supplied with the Burner Kit
BURNER & TUBE KIT ASSEMBLY CHART
MODEL: STR-JZ
Residential Garage / Workshop Heater
TS-4510-JZ 10
FT
TS-1420-JZ 20
FT
TS-1430-JZ 30
FT
10' 1
20' 1
20' 1
30' 1
TUBE KIT PART # & QUANTITY
REQUIRED
60,000
Stand-Alone Tube Kits Only
45,000
BURNER KIT
FIRING RATE
