Schwank ecoSchwank-X 52 - Manual (Page 27)

27
ECO-X 36-52 / IL-X 150-200 Manual
IM100116
RD: MAY 2009
RL: 05A - BA
18. HIGH ALTITUDE INSTALLATION
This heater not to be installed at altitude above 6,800 feet.
USA:
The factory installed orifice for this appliance is approved for altitudes zero to 2000
feet above sea level. When installed above 2000 feet, refer to information below.
Canada
: The factory installed orifice for this appliance is approved for altitudes zero to
4500 feet above sea level. When installed above 4500 feet, refer to information below.
When this appliance is installed above the standard altitude stipulated for the USA or Canada,
the input must be de-rated by 4% for each 1000 ft above sea level. The orifice must be
changed according to the chart below - ensure you search the correct model. Check with your
local utility regarding the gas supply and the de-rating of this appliance.
NOTE: ecoSchwank-X 36, 52 & IL-X 150, 200
EACH HEATER REQUIRES TWO ORIFICES OF THE SIZE LIST BELOW
(ONE FOR EACH BURNER PANEL)
MODEL
FOR USE AT ALTITUDES ABOVE (FEET)
2 Orifices Required - Gas Orifice Drill Size 1 / Part#
Supplied USA Only USA & CANADA
0 2000 3000 4000 5000 6000
DO NOT INST
ALL
A
T
AL
TITUDE ABOVE
6,800 F
EET
ecoSchwank-X 36 NG
IL-X 150 NG
29 DMS
JX-0729-DM
29 DMS
JX-0729-DM
30 DMS
JX-0730-DM
30 DMS
JX-0730-DM
30 DMS
JX-0730-DM
30 DMS
JX-0730-DM
ecoSchwank-X 36 LPG
IL-X 150 LPG
42 DMS
JX-0742-DM
42 DMS
JX-0742-DM
43 DMS
JX-0743-DM
43 DMS
JX-0743-DM
43 DMS
JX-0743-DM
44 DMS
JX-0744-DM
ecoSchwank-X 52 NG
IL-X 200 NG
19 DMS
JX-0719-DM
20 DMS
JX-0720-DM
20 DMS
JX-0720-DM
21 DMS
JX-0721-DM
22 DMS
JX-0722-DM
23 DMS
JX-0723-DM
ecoSchwank-X 52 LPG
IL-X 200 LPG
33 DMS
JX-0733-DM
35 DMS
JX-0735-DM
35 DMS
JX-0735-DM
36 DMS
JX-0736-DM
36 DMS
JX-0736-DM
37 DMS
JX-0737-DM
1 Table values as per ANSI Z223.1 (NFPA 54)
