Schwank supraSchwank - Manual (Page 36)

supra/primo Manual
IM091112
RD: APR 2013
RL: 13B
36
24. PARTS LIST
ITEM PART NUMBER PART DESCRIPTION MODEL
1 JO-0370-XX CERAMIC TILE
2 JO-0343-XX TILE RETAINER STRIP (2 PER 3 TILES)
2a JO-0344-XX TILE HOLDER (2 PER 3 TILES)
3 PRIMO - MAIN BURNER ORIFICE
JO-0310-LP
PRIMO 10 LP PRIMO ONLY
JO-0310-NG PRIMO 10 NG PRIMO ONLY
JO-0313-LP PRIMO 15 LP PRIMO ONLY
JO-0313-NG PRIMO 15 NG PRIMO ONLY
JO-0311-LP PRIMO 20 LP PRIMO ONLY
JO-0311-NG PRIMO 20 NG PRIMO ONLY
JO-0312-LP PRIMO 30 LP PRIMO ONLY
JO-0312-NG PRIMO 30 NG PRIMO ONLY
3 SUPRA - MAIN BURNER ORIFICE
JU-0319-LP SUPRA 10 LP - 1.50mm SUPRA ONLY
JU-0319-NG SUPRA 10 NG - 2.35mm SUPRA ONLY
JU-0318-LP SUPRA 15 LP - 1.85mm SUPRA ONLY
JU-0318-NG SUPRA 15 NG - 2.85mm SUPRA ONLY
JU-0320-LP SUPRA 20 LP - 2.18mm SUPRA ONLY
JU-0320-NG SUPRA 20 NG - 3.35mm SUPRA ONLY
JU-0321-LP SUPRA 30 LP - 2.60mm SUPRA ONLY
JU-0321-NG SUPRA 30 NG - 4.05mm SUPRA ONLY
4 ORIFICE HOLDER
JO-0307-XX PRIMO / SUPRA 10
JO-0307-AA PRIMO / SUPRA 15
JO-0308-XX PRIMO / SUPRA 20
JO-0309-XX PRIMO / SUPRA 30
5 PRIMO - VENTURI AERATION RESTRICTOR PLATE
JO-0375-XX MODEL PRIMO 10 (LP) (L.A.) # 45 PRIMO ONLY
JO-0375-XX MODEL PRIMO 15 (LP) (L.A.) # 45 PRIMO ONLY
JO-0376-XX MODEL PRIMO 15 (NG) (L.A.) # 48 PRIMO ONLY
JO-0377-XX MODEL PRIMO 20 (LP) (L.A.) 55 X 73 PRIMO ONLY
5 SUPRA - VENTURI AERATION RESTRICTOR PLATE
JO-0373-XX MODEL SUPRA 10 (LP) # 37 SUPRA ONLY
JO-0373-XX MODEL SUPRA 10 (NG) # 40 SUPRA ONLY
JO-0373-XX MODEL SUPRA 15 (LP) # 40 SUPRA ONLY
JO-0377-XX MODEL SUPRA 20 (LP) # 55 SUPRA ONLY
JO-0377-XX MODEL SUPRA 30 (NG) # 55 SUPRA ONLY
6 JO-0315-XX ½" X ½" UNION
7 JS-0588-XX ½" X 90 DEGREE ELBOW
8 JO-0316-XX ½' NIPPLE
9 COMBINATION GAS VALVE
JL-0701-XX HONEWELL VR8205A2065B - 5"W.C. NG
JL-0703-XX HONEWELL VR8205A2016B - 11"W.C. LP
