Page 55 – Bunn C User Manual
Page 55
Page 55
T1
T5 T3
T4
T2
BLK-14
BLK-14
120V AC 2 WIRE
120/208V AC 3 WIRE
120/240V AC 3 WIRE
SINGLE PHASE
WHI-14
WHI
WHI
WHI/RED
WHI/RED
WHI
WHI/GRN
WHI/BLU
WHI/VIO-14
BLU-14
RED-14
TANK HEATER
TANK HEATER
SELECTOR
SWITCH
10836.0010B 02/07 ©2001 BUNN-O-MATIC CORPORATION
BLK
BLK
BLK
BLK
BLU
BLU
WHI/RED
WHI
HEATER
SWITCH
ON/OFF
SWITCH
BLU
LIMIT
THERMOSTAT
READY INDICATOR
SW. & THERMOSTAT
BREW
TIMER
SOL
START SWITCH
"KEEP WARM" HEATER
SCHEMATIC WIRING DIAGRAM
CWT, CWTF - APS, TS, TC DV
THERMAL
SAFETY FUSE
(Faucet models only)
GRN
BLK
N
L1
L2
WHI
BLK
RED
MAIN ON/OFF SWITCH
(Late Models only)
41711.1 052009
