2 • 65-2340RK Toxic Gas Transmitter
Description
This section describes the components of the toxic gas transmitter. The toxic gas
transmitter is a 4 - 20 mA type detector head. It consists of the toxic detector, amplifier,
and junction box.
Figure 1: Toxic Transmitter Component Location
Factory Adjust Pot
Controller Terminal Strip
Amplifier
Mounting Screw
Detector Terminal Strip
Black - Test Point
Red + Test Point
J-Box
Span Pot
Zero Pot
ZE
R
O
SP
A
N
T
O
X
IC
O
X
Y
SI
G
/PW
R
S
Toxic Detector
