Controller lel detector terminals – RKI Instruments 61-1007RKSS User Manual
Page 10
6 • 61-1007RKSS Carbon Dioxide Gas Detector
Figure 4: Wiring the CO
2
Detector to a Controller
9.
If using shielded cable, connect the cable’s drain wire to an available chassis ground at
the controller. RKI controllers typically have a ground stud that is a convenient
grounding location.
Controller LEL
Detector Terminals
BLACK
RED
WHITE
GREEN
Cable Shield
Black
IR CO2 Detector
Green
J-Box
Red
White
