3 • Description
Model GP-01 Operator’s Manual
Description
This section describes the components of the Model GP-01. These
components include the GP-01’s protective rubber boots, case, membrane
retainer and filter disks, sensor retainer, sensor, LCD, control buttons,
printed circuit boards, alarm lights, buzzer, vibrator, and batteries.
LCD
Control Buttons
Alarm Lights
Buzzer Opening
Membrane
Retainer
Sensor
Retainer
Battery Cover
Battery Charging
Contacts
POWER
MODE
AIR
GP-01
%LEL
Sensor End
Boot
Battery End
Boot
Threaded
Inserts
Figure 1: Components of the GP-01
