Practical Instrument Electronics
82 East Main Street Suite 3.14 • Webster, NY 14580 Tel: 585.872.9350 • Fax: 585.872.2638 • [email protected] • www.piecal.com
Configuration
Configure the Calibrator
Move w POWER SWITCH to “SOURCE” or
“READ”.
Setup
Double click the
e DIAL KNOB at any time the
unit is on and the following displays will appear
for 15 seconds:
Turn the
e DIAL KNOB to move through the
three pages of menus. Press the e DIAL KNOB
to toggle between OFF and ON or to scroll
through the settings.
EXIT - exits this menu immediately and saves
any changes. Menu will automatically exit after
15 seconds of inactivity.
UNITS - pressing the knob will toggle between
°C and °F.
FUNCTION - pressing the knob will toggle
between T/C and V. Select T/C for thermocouple
or V for the -13.000 to 80.000 mV range.
T/C TYPE - pressing the knob will cycle through
T/C types J, K, E & T.
MODEL 322 V#.##
DOUBLE CLICK
EZ-DIAL KNOB
FOR CONFIGURATION
COLD JUNC - Automatic COLD JUNCTION
(Cold Junction Compensation) may be turned
on or off. It is recommended that CJC be left on
(default). CJC should only be turned off if an
external cold junction compensator or ice bath is
used with the PIECAL 322.
AUTO OFF - If AUTO OFF is ON, the unit will
turn off after 30 minutes of inactivity to save
battery life. If AUTO OFF is OFF the unit will stay
on until the POWER SWITCH is moved to the off
position.
BACKLIGHT - If BACKLIGHT is ON the
backlight will light all the time the unit is powered
up. For maximum battery life turn the backlight
off when using the calibrator in areas with
enough ambient light to read the display.
STEPS/RAMP - pressing the knob will cycle
through 2, 3, 5, 11 and RAMP. The endpoints of
the steps or ramp are based on the values
stored in the
HI and LO EZ-CHECK outputs.
2 steps will automatically switch between the
values stored in the HI & LO EZ-CHECK (0 &
100%).
3 steps between the HI, Midpoint and LO
EZ-CHECK (0, 50 & 100%).
5 steps between the HI and LO EZ-CHECK
in 25% increments (0, 25, 50, 75 & 100%).
11 steps between the HI and LO EZ-CHECK
in 10% increments (0, 10, 20...80, 90 &100%).
RAMP continuously ramps up and down
between the HI and LO EZ-CHECK outputs.
STEP/RAMP TIME - pressing the knob will cycle
through 5, 6, 7, 8, 9, 10, 15, 20, 25, 30 and 60
seconds.
Note: All settings are remembered even with the
power off. Removing the batteries resets the
values to factory defaults.
MAIN
> EXIT (1/2)
FUNCTION T/C V
UNITS °C °F
T/C TYPE J K E T
COLD JUNC ON OFF
FEATURES
> EXIT (2/2)
AUTO OFF ON OFF
BACKLIGHT ON OFF
STEPS/RAMP 2 3 5 11 RAMP
STEP/RAMP TIME 5 6 7 8 9 10 15 20 25 30 60
