Technical Specifications
Legion 5500mAh
Legion 11000mAh
Battery
Battery
Weight
Weight
Human Interface
Human Interface
Fail Safe
Fail Safe
Charge Input
Charge Input
Intellectual Properties
Intellectual Properties
Storage Temperature
Storage Temperature
Charge Output
Charge Output
Enclosure
Enclosure
Operating Temperature
Operating Temperature
Meters
Meters
Display
Display
Power Supply
Power Supply
Physical Dimensions
Physical Dimensions
Lithium Polymer 5500mAh
Lithium Polymer 11000mAh
0 – 45 Deg Celsius
0 – 45 Deg Celsius
PLX proprietary intelligent battery monitoring and metering.
PLX proprietary intelligent battery monitoring and metering.
USB Female A 5.0V Single 1A (5500mAh)
USB Female A 5.0V Dual 1A, 2A (11000mAh)
-10 – 45 Deg Celsius
-10 – 45 Deg Celsius
Processor controlled high efficiency DC/DC Boost with low power sleep
Processor controlled high efficiency DC/DC Boost with low power sleep
Micro USB 5.0V
Micro USB 5.0V
2.43 x 4.32 x 0.52” (6.17 x 10.97 x 1.33cm)
3.7 x 5.33 x 0.52” (9.39 x 13.53 x 1.33cm)
Temperature monitoring, overcharge protection, short circuit and current over-
draw protection
Temperature monitoring, overcharge protection, short circuit and current over-
draw protection
High Contrast OLED 128 x 32 Pixels
High Contrast OLED 128 x 32 Pixels
4.4oz
9oz
Voltage, Current (in/out), Power, Actual Capacity, Charge Status, Temperature,
Age, Time to Empty, Time to Charge, Health
Voltage, Current (in/out), Power, Actual Capacity, Charge Status, Temperature,
Age, Time to Empty, Time to Charge, Health
1 Push Button
1 Push Button
Magnesium, ABS Plastic
Magnesium, ABS Plastic
Patents Pending
