Models 506 – Bolens 506 User Manual
Page 19
19
Models 506
Ref.
No.
Part No.
Part Description
1.
747-1161A
Blade Control Handle
2.
749-1092A
Upper Handle
3.
746-1130
Blade Control Cable - B&S 40” LG
4.
710-1205
Eye Bolt
5.
720-0279
Wing Nut
6.
720-0284
Wing Nut
7.
736-0451
Shoulder Washer .320 ID x .93 OD
8.
710-1174
Carriage Bolt 5/16-18 x 2.0
9.
725-0157
Cable Tie
10.
749-04037
Lower Handle
11.
712-0130
Hex Lock Nut 3/8-16
12.
782-9065
Hinge Clip
13.
731-2537
Trail Shield
14.
682-3062A
Handle Bracket Assembly - RH
15.
682-3063A
Handle Bracket Assembly - LH
16.
736-3050
Flat Washer .406 ID x .812 OD
17.
712-0130
Hex Lock Nut 3/8 -16
18.
710-0654A
Hex Washer Screw 3/8-16 x 1.0
19.
687-02045
Deck Assembly 22”
687-02048
Deck Assembly 22” (No Sprigs)
20.
736-0270
Bell Washer .265 x .75
21.
741-0751
Height Adjuster Bearing
22.
682-0113
Pivot Arm Assembly
23.
748-0376C
Blade Adapter
24.
742-0742A
Mulching Blade 22”
25.
710-1044
Hex Cap Screw 3/8-24 x 1.5
26.
736-0524A
Blade Bell Support
27.
738-1172
Shoulder Screw 3/8 - 16 x .302
28.
736-0741
Bell Washer .760 ID x 1.25 OD
29.
734-1988
Front Wheel Assembly 7 x 1.8
31.
720-0426
Height Adjuster Knob
32.
732-1026
Front Spring Lever
33.
747-0710
Hinge Pin
34.
732-1014
Torsion Spring
35.
731-1035B
Chute Hinge
36.
731-1034B
Side Discharge Chute Assembly
38.
710-0216
Hex Cap Screw 3/8-16 x .75
39.
741-0717
Thrust Bearing .688 ID x 1.938 OD
40.
682-0093
Rear Pivot Arm Assembly
41.
732-0984B
Rear Spring Lever
42.
738-1127
Shoulder Screw 3/8 - 16 x .442
43.
736-0182
Spring Washer
44.
734-1864
Rear Wheel Assembly 14 x 1.8
46.
731-04197
Snap Mulching Plug
47.
736-0105
Washer Spacer .401 ID x .870 OD
Ref.
No.
Part No.
Part Description
