Manual Text Booklet – Orbit Baby Double Helix Stroller Frame – ENGLISH – 11
Loading your child into the rear SmartHub seat
⃞ Rotate the infant car seat by pulling one or both levers and rotating the seat into the sideways
loading position. Rotate the stroller seat or bassinet by pulling both levers and rotating the seat to a
sideways loading position.
⃞ Place your child in the seat and secure according to the seat’s instruction manual. Rotate the seat
forward-facing to begin strolling.
Restrictions on the double stroller frame
⃞ Never use both stroller seats in the fully reclined position as shown in the diagram; a child’s feet
could become pinched between the footrests. Avoid injury to the child in rear seat from kicking or
contact with footrest on stroller seat; only use footrest adjustment position 1 when stroller seat is
rear-facing on the front SmartHub.
⃞ The Orbit Baby bassinet, infant car seat, stroller seat or toddler car seat can be used on the front
SmartHub. The bassinet, infant car seat and toddler car seat will lock in four rotational positions.
The stroller seat will lock in two rotational positions (front and rear-facing).
The Orbit Baby bassinet, infant car seat or stroller seat can be used on the rear SmartHub. The
seats must face forward for strolling but may be positioned to the side for loading.
⃞ Maximum child weight on either SmartHub (front or rear) is 40 lbs (18 kg). Maximum height for the
rear SmartHub is 34 in (86 cm). Note that 34 in (86 cm) is a reduced height limit for the
stroller seat when used on the Helix SmartHub Attachment.
Using Your Double Stroller
Adjusting the handlebar
⃞ To adjust the handlebar to your desired position, fully open both handlebar levers Ⓙ with your
thumbs, rotate and/or telescope the handlebar, and then relock the handlebar levers closed.
⃞ There are three different handlebar rotation positions (denoted with lines) and two telescoping
positions (position 1 or position 2).
