8 – ENGLISH – Manual Text Booklet – Orbit Baby Double Helix Stroller Frame
Assembling the stroller frame
⃞ Insert the rear wheels into the rear legs. You will hear a CLICK when they are locked in place.
⃞ Insert the front wheels into the front cross brace. Note that the front wheels have a long metal rod
coming out of the fork while the wheels for the Helix SmartHub Attachment have a short metal rod.
You will hear a CLICK when they are locked in place.
Attaching the stroller basket
⃞ Insert the stroller basket handle Ⓛ into the rail on the underside of the front SmartHub. You will hear
a CLICK when it locks in place.
⃞ To secure the front of the basket, insert one of the plastic handles Ⓜ into the opening on the front
part of the stroller frame. Hold it in place while inserting the other plastic handle into the opening on
the other side of the stroller frame.
⚠
WARNING
⚠
PINCH HAZARD:
◦
Avoid injury from pinching or finger entrapment. Keep children away when inserting the
Helix SmartHub Attachment. Keep your hands clear of moving parts when inserting and
removing the Helix SmartHub Attachment.
FALL HAZARD:
◦
Always check that the Helix SmartHub Attachment is securely locked into the stroller frame
leg connectors before placing your child into stroller or starting to stroll. Pull backwards on
the Helix SmartHub Attachment and check that the red warning triangles on both sides are
NOT visible.
Assembling and attaching the Helix SmartHub Attachment
⃞ Insert the two Helix SmartHub Attachment wheels Ⓡ. You will hear a CLICK when they are locked
in place.
⃞ Grasp the Helix SmartHub Attachment with one hand while holding the stroller frame with your other
hand. Pull on the release lever Ⓝ and guide both tube ends into the frame leg connectors Ⓣ until
