Manual Text Booklet – Orbit Baby Double Helix Stroller Frame – ENGLISH – 9
they are fully inserted and the red warning triangles have been fully covered by the stroller frame leg
connectors. You will hear a CLICK when the Helix SmartHub Attachment is locked in place. Check
that the Helix SmartHub Attachment is fully locked into the stroller frame by letting go of the release
lever and pulling back on the attachment. You should not see the red warning triangles or be able
to remove the attachment.
⚠
WARNING
⚠
PINCH HAZARD:
◦
Keep hands and fingers clear of moving parts when adjusting the handlebar.
◦
Always maintain control of the handlebar after opening the handlebar levers to avoid
contact with the child in the rear seating positon.
Unfolding the handlebar
⃞ Unfold the handlebar by fully opening both handlebar levers Ⓙ with your thumbs. Then rotate and
pull the handlebar to your desired position.
⃞ Note there are three different handlebar rotation positions (denoted with lines) and two telescoping
positions (position 1 or position 2).
⃞ Lock the handlebar into position by closing both handlebar levers.
Attaching the ShadePad
⃞ Undo the hook and loop fasteners on the backside of the ShadePad Ⓐ. Grasp the ShadePad by
its sides and slide it over the handlebar while pulling it wide open, until the bottom of the ShadePad
lines up with the end of the foam grip. Ensure that the clear window faces upward, the flap with
the two snaps faces the handlebar, and the ShadePad is only on the foam of the handlebar.
⃞ Attach the strips of hook and loop fastener on the underside of the ShadePad. Make sure that in
doing so the upper two elastic bands remain covered.
⃞ Snap both corners of the ShadePad to the water bottle tray Ⓚ.
Assembly of the Orbit Baby Double Helix Stroller is now complete.
