www.radiall.com
10-31
BNC
ADDITIONAL CONNECTORS
For more information regarding these connectors, please consult us.
CONNECTORS WITH fLAT GASKET
50Ω CONNECTORS fOR 75Ω or 93Ω CABLE
75Ω Cable
75Ω CONNECTORS fOR 93Ω CABLE
CONNECTORS fOR BT OR SPECIAL CABLES
93Ω Cable
P/N Description Captive center contact
R141 007 000 Straight plug clamp type for 5/50/S+D cable
no R141 011 000 Straight plug clamp type for 6/75/S cable
R141 015 000 Straight plug clamp type for 6/75/S cable
R141 154 000 Right angle plug clamp type for 2.6/50/S+D cable yes
R141 256 000 Straight square flange jack clamp type for 5/50/S+D cable
no R141 257 000 Straight square flange jack clamp type for 5/50/S cable
R141 261 000 Straight square flange jack clamp type for 6/75/S cable
R142 017 000 Straight plug clamp type for 8/75/S+D cable (unit packaging) yes
P/N Description Captive center contact
R141 004 000 Straight plug clamp type for 2.6/75/S cable yes
R141 011 000 Straight plug clamp type for 6/75/S cable
no
R141 012 000 Straight plug clamp type for 6/75/S cable
R141 013 000 Straight plug clamp type for 6/75/S cable no
R141 015 000 Straight plug clamp type for 6/75/S cable no
R141 154 000 Right angle plug clamp type for 2.6/75/D cable yes
R141 261 000 Straight square flange jack clamp type for 6/75/S cable no
R141 277 000 Straight insulated square flange jack clamp type for 2.6/75/S cable
yes
R141 278 000 Straight square flange jack clamp type for 2.6/75/S cable
R141 329 000 Straight bulkhead jack clamp type for 6/75/S cable
P/N Description Packaging
R142 016 000 Straight plug clamp type for 6/93/S cable unit
R142 078 161 Straight plug crimp type for 3.8/93 cable 100 pieces
P/N Description Packaging
R141 003 420 Straight plug clamp type for 2.2/50D cable unit
R141 005 000 Straight plug clamp type dia 3.5/50, PPD cable
100 pieces R141 015 000 Straight plug clamp type dia 6/75/S, 75PD cable
R142 081 100 Straight plug crimp type for 3.6/75/D, P46431 cable
R142 081 120 Straight plug crimp type for BT3002, TZO 75024 cable
unit
R142 081 320 Straight plug crimp type for BT2001 cable
R142 091 161 Straight plug crimp type for ST212 cable 100 pieces
P/N Description Captive center contact
R141 013 000 Straight plug clamp type for 6/93/S cable no
R141 077 000 Straight plug crimp type for 3.8/93/S cable yes
R141 R142
BNC 50Ω BNC 75Ω
