Page 19
10-19
BNC 50Ω
BULKHEAD JACKS
STRAIGHT BULKHEAD JACKS CLAmP TYPE
STRAIGHT BULKHEAD JACKS CRImP TYPE fOR fLEXIBLE CABLES
Fig. 1
Fig. 1
Fig. 3
Fig. 2
Fig. 2
Fig. 4
Cable group
Cable group
dia.
Part number Fig.
Dimensions (mm) Captive center
contact
Panel
drilling
Note
A
B
RG178/RG196
2/50/S
R141 323 000
1
2.2
0.6
yes
P14
Panel sealed
RG174/RG316
2.6/50/S
R141 304 000
2
Totally sealed
R141 324 000
1
3.1
0.6
Panel sealed
RG174/RG316/RD316
2.6/50/S + D
R141 324 200
1
3.1
0.6
yes
RG58/RG141/RG142/RG223/RG400
5/50/S + D
R141 327 000
1
5.6
1.05
no
RG401
.141"
R141 338 007
1
3.68
1.27
yes
Panel sealed,
non magnetic
Cable group
Cable group
dia.
Part number Fig.
Dimensions (mm) Captive center
contact
Panel
drilling
Note
A
B
C
RG174/RG316
2.6/50/S
R141 306 000
1
34
1.7
0.6
yes
P18
R141 306 503
2
26
2.95
Reverse crimping/
commercial version
R141 331 500
3
38.5
1.7
P14 or P20
Panel sealed
R141A 306 000
1
31
1.7
0.6
no
P18
ECO version
R141A 331 500
3
34
1.6
0.7
no
P14
Panel sealed
ECO version
RG58/RG141
5/50/S
R141A 332 161
3
34
3.1
1.2
no
Panel sealed
ECO version
R141 308 000
4
yes
P18
Single piece body
R141 332 161
3
35.5
3.1
1.05
P14 or P20
Panel sealed/
commercial version
R141 332 500
Panel sealed
Reverse crimping/
single piece body
For other types of cables (75Ω, 93Ω or BT cables), please see "additional connectors" on page 10-32.
To download data sheets and assembly instructions, visit www.radiall.com & enter the part number in the Search box.
Bold
part numbers represent products typically in stock & available for immediate shipment.
See page 8 and 9 for packaging information.
