7
840 Series
Straight spill layout for arrangements 11-21-31 and 41
Dimensions
Plug type 8
Cable connecting receptacle type 5
Terminations viewed from female rear face (soldering side)
hole sizes : 0.9 mm
shells
dim.
1 2 3 4 5 6
To calculate overall dimensioning of connector and backshell
assembly, add the 2 dimensions B of each part.
Example :
Plug type 8 + backnut (002) shell size 1 = 31.5 + 2.5 = 34 mm
Receptacle type 1 + backnut (002) shell size 1 = 27.5 + 2.5 = 30 mm
B* includes retention cone
840 Series
A
22.50
.89
26.50
1.04
33
1.30
39
1.54
51
2.01
65
2.56
B*
31.50
1.24
31.50
1.24
31.50
1.24
31.50
1.24
42.70
1.68
42.70
1.68
shells
dim.
1 2 3 4 5 6
A
16
.63
20
.79
26
1.02
31
1.22
43
1.69
57
2.24
B*
27.50
1.08
27.50
1.08
27.90
1.10
27.90
1.10
39.10
1.54
39.10
1.54
C
14.50
.57
14.50
.57
15.50
.61
15.50
.61
15.50
.61
15.50
.61
