840 Series
Contact layouts and polarizations
Viewed from front face of male insulator
Available arrangements :
■ crimp only (specification 002)
▲ spill contacts
❏ solder only ● in SP1
✶ in 008
SP1 and 008 silver plated solder contacts only, the longest contact is always
loaded in the cavity identified as 1 in insulator.
shell
1
shell
2
shell
3
shell
4
shell
5
shell
6
3 Ш 1,5
11 ● ✶ ▲
2 Ш 1,5
12 ● ✶ ▲
1 Ш 3,5
13 ● ✶ ■
7 Ш 1
19 ● ✶ ■
7 Ш 1,5
21 ● ✶ ▲
1 Ш 1,5
2 Ш 2,5
22 ● ✶ ▲
3 Ш 2,5
23 ● ● ✶
4 Ш 2,5
24 ● ✶ ●
3 Ш 1,5
26 ● ✶ ●
12 Ш 1
29 ● ✶ ■
12 Ш 1,5
31 ● ✶ ▲
3 Ш 3,5
32 ● ✶ ▲
4 Ш 3,5
33 ● ● ✶
2 Ш 3,5
4 Ш 1,5
34 ● ✶ ▲
1 Ш 10
35 ● ✶ ❏
19 Ш 1
39 ● ✶ ■
19 Ш 1,5
41 ● ✶ ▲
37 Ш 1,5
51 ● ✶ ●
4 Ш 7
65 ● ✶ ●
19 Ш 2,5
52 ● ✶ ●
26 Ш 1,5
53 ● ✶ ●
61 Ш 1
54 ● ✶ ■
8 Ш 1,5
4 Ш 2,5
42 ● ✶ ▲
4 Ш 3,5
8 Ш 1,5
43 ● ✶ ▲
6 Ш 2,5
6 Ш 1,5
44 ● ✶ ▲
4 Ш 5
45 ● ✶ ❏
2 Ш 2,5
12 Ш 1,5
46 ● ✶ ▲
37 Ш 1
12 Ш 1,5
49 ● ✶ ■
