DCA-400SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (09/17/01) — PAGE 93
ENCLOSURE #1 ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 C3414000202 BASE ............................................................. 1 .......... S/N3692434 TO 3701676
C3414001902 BASE ............................................................. 1 .......... S/N3701677~
2 C3414100104 FLOOR PANEL 1
3 C3414100004 FLOOR PANEL 1
4 0019208020 HEX. HEAD BOLT 14
5 C3424001204 FRONT FRAME 1
C3494100903 LINING ........................................................... 1 .......... S/N3692434 TO 3701676
C3494101703 LINING ........................................................... 1 .......... S/N3701677~
6 C342400103 FRONT FRAME 1
C3494100903 LINING ........................................................... 1 .......... S/N3692434 TO 3701676
C3494101703 LINING ........................................................... 1 .......... S/N3701677~
7 C3424000202 FRONT FRAME 1
C3494100903 LINING ........................................................... 1 .......... S/N3692434 TO 3701676
C3494101703 LINING ........................................................... 1 .......... S/N3701677~
8 C3424000302 FRONT FRAME 1
C3494100903 LINING ........................................................... 1 .......... S/N3692434 TO 3701676
C3494101703 LINING ........................................................... 1 .......... S/N3701677~
9 0017108020 HEX. HEAD BOLT 20
10 C3424300403 GUIDE PANEL, AIR ....................................... 1 .......... S/N3692434 TO 3701676
C3424300603 GUIDE PANEL, AIR ....................................... 1 .......... S/N3701677~
C3494100903 LINING ........................................................... 1 .......... S/N3692434 TO 3701676
C3494101703 LINING ........................................................... 1 .......... /N3701677
11 C3424300303 GUIDE PANEL, AIR 1
C3494100903 LINING ........................................................... 1 .......... S/N3692434 TO 3701676
C3494101703 LINING ........................................................... 1 .......... S/N3701677~
12 0019208020 HEX. HEAD BOLT 24
13 0019210025 HEX. HEAD BOLT 8
14 C3424201403 COVER, FRONT FRAME 1
15 C3424201304 COVER, FRONT FRAME 1
C3494101004 LINING 1
16 0019208020 HEX. HEAD BOLT 28
DCA-400SSK — ENCLOSURE #1 ASSY.
THE DEFAULT PART NUMBER FOR THE COLOR ORANGE.
PLEASE INDICATE COLOR WHEN ORDERING:
MQW-WHITE
MQGRN-GREEN
THE SERIAL NUMBER MAY BE REQUIRED.
