page 20 — DCa45SSIU4 60 hz generator • operatIon anD partS manUal — rev. #1 (10/24/13)
engine Operating paneL
Figure 5. Engine Operating Panel
1000 2000
3000 0
R P M
OFF
W U
V
OFF
W-U
V-W
U-V
DECREASE INCREASE
AUTO MANUAL
OFF/RESET
LOW OIL PRESSURE
HIGH COOLANT TEMPERATURE
OVERCRANK
OVERSPEED
ENGINE RUNNING
MOOOOO-20001Q
1
2
3 4
5
6
7
8
9
10
11
